Shuttle XPC Nano Barebone NC02U Intel I3-6100U ,HD-GRAPHICS,65W - Desktop

2.704,87 lei
cu TVA
Stoc epuizat

  Politia de Garantie

Persoanele juridice au garantie de 12 luni.

  Politica de Livrare

Oferim livrare exclusiv prin serviciul Sameday.

  Politica de Return

Return gratuit in 14 zile.

  Locatie Fizica

Bucuresti & Craiova

Barebone PC with a black plastic chassis
Dimensions: 142 x 142 x 42 mm (LWH) = 835 ml
Weight: 0.4 kg net, 1.2 kg gross
Hole for Kensington Lock
Includes vertical stand and 75 / 100 mm VESA mountLow Power Consumption
Power consumption in idle mode: 6.7~7.8 W, full load: 15,7 / 33,8 W (without/with graphics)
(measured with 2x 4 GB DDR3L SO-DIMM, 120 GB 2.5" SSD, Windows 10-1607 64 bit)Operation Position
1) Horizontal
2) Vertical with stand
3) VESA-mounted behind an appropriate monitorOperation System
This barebone system comes without operating system.
It is compatible with:
- Windows 7, 64-bit
- Windows 8.1, 64-bit
- Windows 10, 64-bit
- Linux (e.g. Ubuntu, OpenSUSE, Fedora), 64-bitProcessor
Model: Intel Core i3-6100U (ULV)
System-on-a-chip architecture (SoC): no chipset required
BGA1356 package - directly soldered onto the mainboard
Code name: Skylake-U (6th Generation Intel Core)
Cores / Threads: 2 / 4
Clock rate: 2.3 GHz
L1/L2/L3 Cache: 128 kB / 512 kB / 3072 kB
Memory controller: DDR3L-1600 Dual Channel (1.35 V)
TDP wattage: 15 W maximum
Manufacturing process: 14 nm
Maximum Tjunction Temperature: 100 °C
Supports 64-bit, VT-x (EPT), VT-d, Enhanced SpeedStep, NX bit, AES-NI, SSE 4.1/4.2
Integrated graphics engineCooling Fan
Built-in CPU cooling fan with 4 pin connector
Supports temperature-controlled RPM fan speedIntegrated Graphics
Intel HD graphics 520 (Intel HD Gen. 9)
Two digital audio/video ports support two independent screens:
1) DisplayPort 1.2 [1] supports 3840 x 2160 @ 60Hz
2) HDMI 1.4b supports 3840 x 2160 @ 24Hz
Supports Ultra HD / 4K resolution
GPU clock rate: 300~1000 MHz
Execution Units (EU): 24
Supports DirectX 12, OpenGL 4.4
Supports full H264, H265 8/10-bit, VP8/9, VC-1, AVC hardware decoding
Supports Quick Sync Video and Clear Video HD technology
Supports HD video plus multi-channel digital audio via a single cable
Dynamic, shared memory: up to 1.7 GB
Note: dual channel memory (two identical modules) is required for 4K Ultra-HD resolution (2160p) support.Mainboard / BIOS
AMI BIOS in 8 MByte EEPROM with SPI interface
Supports resume after power failure
Supports Wake on LAN (WOL)
Supports Power on by RTC Alarm
Supports booting from USB devices and SD card reader
Supports hardware monitoring and watch dog function
Supports Unified Extensible Firmware Interface (UEFI)
Supports Firmware TPM v2.0 (fTPM) since BIOS version NC02U000.103Power Adapter
External 65 W power adapter (fanless)
Input: 100~240 V AC, 50/60 Hz, max. 1.6 A
Output: 19 V DC, max. 3.42 A, max. 65 W
DC Connector: 5.5 / 2.5 mm (outer/inner diameter)Memory support
2x 204-pin SO-DIMM slot
Supports DDR3L-1600 (PC3-12800) SDRAM at 1.35 V
Supports Dual Channel mode
Supports a maximum of 16 GB per DIMM, maximum capacity: 32 GB
Supports two unbuffered DIMM modules (no ECC)
Note: This mainboard does only support 1.35V DDR3L memory modules. DDR3L has a lower operation voltage as DDR3.2.5" Drive Bay
Supports one Serial ATA hard disk
or one SATA SSD drive in 6.35 cm / 2.5" format
Device height: 15 mm (max.)
Supports Serial-ATA III, 6 Gb/s (600 MB/s) bandwidthCard Reader
Integrated SD card reader
Supports SD, SDHC and SDXC memory flash cards
Supports booting from SD cardM.2 Slot for SSDs
The M.2 2280 BM slot provides the following interfaces:
- PCI-Express Gen. 2.0 X4 with up to 32 Gbps Data Transfer Speed
- SATA v3.0 (max. 6 Gbps)
It supports M.2 cards with a width of 22 mm
and a length of 42, 60 or 80 mm (type 2242, 2260, 2280).
Supports M.2 SATA SSDs (with B+M key) and M.2 PCIe SSDs (with M key)Audio
Audio Realtek® ALC 662 High-Definition Audio Codec
3.5 mm / 4-pole combo audio connector for headphones and microphone [2]
Digital multi-channel audio output: via HDMI and DisplayPort Gigabit LAN
Ethernet Controller Intel i211
Supports 10 / 100 / 1.000 MBit/s operation (Gigabit)
Supports WAKE ON LAN (WOL)
Supports network boot by Preboot eXecution Environment (PXE)
IEEE 802.3az Energy Efficient Ethernet (EEE)
Interface: PCIe v2.1Wireless LAN
Built-in M.2-2230-A/E WLAN card and internal antenna
Single-Chip 1T1R WLAN Controller Realtek RTL8188EE
Supports IEEE 802.11b/g/n, max. 150 Mbps up-/downstream
Security: WPA/WPA2(-PSK), WEP 64/128 bit, IEEE 802.11x/iFront Panel connectors
USB 3.0 type A
USB 3.0 type C
SD card reader (supports SD, SDHC, SDXC)
Power button
Power LED (blue, blinking when in suspend mode)
HDD LED (orange)Back Panel connectors
DisplayPort 1.2 [1]
HDMI 1.4b
2x USB 2.0
Gigabit LAN (RJ45)
Audio Combo Port for headphones and microphone (3.5 mm jack, 4-pole) [2]
DC-input connector for external power adapter
2x perforation for optional external WLAN antennasLeft Side connectors
Serial RS232 COM port (D-Sub, 9-pin)
Note: The serial connector (COM port) cannot be used if NC02U is operated in vertical position.Always-On Jumper
By removing Jumper JP1 (please refer to the Quick Installation Guide)
the system will start unconditionally once power is applied. [4]Clear CMOS Jumper
Short Jumper JP2 for about 10 seconds in order to reset all BIOS configuration setting to factory default.Supplied Accessories
Multi-language Quick Installation Guide
Driver DVD for Windows
VESA mount set (two parts, made of steel, with 6 screws)
2x aluminium stand with screws for vertical operation
Bracket for a 2.5" drive with 8 screws
Power adapter with AC power cordEnvironmental Spec
Operating temperature range: 0~40 °C [3]
Relative humidity range: 10~90% (non-condensing)Conformity/Certifications
Safety: ETL, CB, BSMI
Other: RoHS, Energy Star, ErP
This device is classed as a technical information equipment (ITE) in class B and is intended for use in living room and office. The CE-mark approves the conformity by the EU directives:
(1) 2004/108/EC relating to electromagnetic compatibility (EMC),
(2) 2006/95/EC relating to Electrical Equipment designed for use within certain voltage limits (LVD),
(3) 2009/125/EC relating to ecodesign requirements for energy-related products (ErP),
(4) 1999/5/EC related to Radio and Telecommunications Terminal Equipment (R&TTE)

[1] How to convert DisplayPort into HDMI/DVI
The DisplayPort outputs can be converted to HDMI or DVI by an additional, passive adapter cable. For example:
DELOCK 82590: 1 m, DisplayPort (male, 20p) to HDMI-A (male, 19p)
DELOCK 82435: 5 m, DisplayPort (male, 20p) to DVI-D (male, 24p)
The integrated graphics automatically detects the connected display and puts out the appropriate electric signal - either DisplayPort (without an adapter) or HDMI/DVI (with an adapter).
However, a monitor with a DisplayPort connector cannot be connected to the HDMI port with a simple, passive adapter. In this case an active adapter like Delock 62496 is required.
Connecting a UHD/4K display via the present HDMI port means the refreshing rate is limited to 24 Hz. 60 Hz can only be achieved by using the DisplayPort port. Should your display have a HDMI 2.0 connector, a refreshing rate of 60 Hz can be achieved by using an active adapter such as the Club 3D CAC-1070 for example.
[2] Audio connector
The 3.5 mm audio jack at the back panel of this device supports both a 4-pole connector for headphones and microphone and headphones with only a 3-pole connector. Headsets with separate connectors for headphones and microphone, though, require an appropriate adapter, if also the microphone should be used.
[3] Caution: for high ambient temperatures over 35 °C we strongly recommend to use SSDs (supporting at least 70 °C) instead of hard disks.
[4] Power on after power fail:
The BIOS setup provides a "Power-On after Power Fail" function that can be found under "Power Management Configuration". This function determines the PC's behaviour after power failure. As a matter of the nature of this function, it may fail after short power failures. This is why this PC also comes with a hardware-based solution. By removing Jumper JP1 (please refer to the Quick Installation Guide) the system will start unconditionally once power is applied.
